Scientists Demonstrate Technique to Protect Fusion Devices from Sudden Energy Loss

Shattering hydrogen and neon pellets into devices provides highly effective energy dissipation.

San Diego, September 1 – An important technique for protecting future fusion energy devices is advancing for use in the world’s largest fusion experiment after validation by an international research team. Originally developed at the DIII-D National Fusion Facility, which is operated by General Atomics (GA) as a User Facility of the U.S. Department of Energy (DOE) Office of Science, the approach will help manage plasma instability for the international ITER experiment under construction in France.

Scientists Demonstrate Technique to Protect Fusion Devices from Sudden Energy Loss
The Shattered Pellet Injection (SPI) research program at DIII-D has recently contributed to an international investigation that identified a common physics basis in the behavior of this disruption mitigation technique. The left column shows two camera images as a shattered pellet reaches the plasma edge (left-top) and then as shards reach the core (left-bottom). The magnetic instabilities measured during deuterium SPI shutdowns show common behavior across DIII-D, JET, and KSTAR (right-top), pointing to common physics that can be extrapolated to future devices. The Oak Ridge National Laboratory (ORNL) leads pellet injection research efforts at DIII-D, with Dr. Daisuke Shiraki shown next to one of the ORNL pellet injection systems (right-bottom).

Specific events during operation of a fusion device can allow hot plasma fuel to rapidly escape the confining magnetic fields. Referred to as “plasma disruptions,” these events can result in the energy contained in the plasma causing damage to the device’s walls.

Pioneering research at DIII-D using Oak Ridge National Laboratory (ORNL) technology led to the development of a mitigation technique known as “shattered pellet injection” (SPI). This approach has shown significant promise in reducing the effects of plasma disruptions.

Based on this work, an international Disruption Mitigation Task Force, established by the ITER Organization, selected SPI as the disruption mitigation technique for ITER. The task force works with facilities around the world to improve the design basis for SPI through experiments and modelling. Experiments at DIII-D are part of this global effort, and the experimental group of the task force is led by GA scientist Nick Eidietis.

“Preventing and mitigating plasma disruptions is key for developing tokamak-based fusion power plants,” said DIII-D scientist Daisuke Shiraki, an ORNL researcher who was part of the U.S. team during the international project to prepare SPI for ITER. “This collaboration was successful in testing the SPI technique at multiple facilities worldwide, demonstrating its usefulness for future devices.”

DIII-D is the largest magnetic fusion research facility in the United States. The heart of the facility is a tokamak that uses powerful electromagnets to produce a toroidal (doughnut-shaped) magnetic bottle for confining a fusion plasma.

Plasma is the fourth state of matter in which electrons are stripped from the atoms, producing a highly ionized “soup” of nuclei and electrons that can be controlled by magnetic fields. On ITER, plasma temperatures more than 10 times hotter than the Sun will be achieved. At such extremely high temperatures, hydrogen isotopes are forced by powerful magnetic forces to fuse together and release energy.

The plasma-facing inner wall in DIII-D is built of graphite that allows for disruption experiments that do not damage the device. However, as fusion devices with metal walls increase in scale and power to the levels required in power plants, the potential damage from such disruption events becomes increasingly significant. Fusion scientists have worked on techniques to mitigate this damage for many years.

The SPI technique developed at DIII-D uses rapid injection of cryogenic shards into the plasma. The quantity, composition, and sequence of pellets can be tailored for most efficient mitigation. To optimize SPI for ITER, studies on other tokamaks were conducted to improve the physics understanding of the SPI shutdown process.

With support of the ITER Organization and Disruption Mitigation Task Force, DIII-D scientists worked with international collaborators at the JET tokamak in the United Kingdom and the KSTAR tokamak in South Korea. The SPI systems for these tokamaks were developed by ORNL, which also leads the implementation and operation of multiple disruption mitigation systems at DIII-D.

By comparing SPI performance on the three devices, the team found common physics that applied across the facilities. The scientific results of this work were presented at a conference held by the International Atomic Energy Agency last year.

The effort was also selected by the DOE as a 2021 Fusion Energy Sciences Joint Research Target, which analyzed results from experiments carried out at DIII-D, JET, and KSTAR, and identified areas of common findings and remaining issues for future research.

This material is based upon work supported by US DOE under contract number DE-FC02-04ER54698, and on work supported by the Oak Ridge National Laboratory managed by UT-Battelle, LLC for DOE under contract no. DE-AC05-00OR22725.
